Vigor160 Series User’s Guide
25
I
I
I
I
-
-
1
1
-
-
2
2
P
P
P
P
P
P
o
o
E
E
/
/
P
P
P
P
P
P
o
o
A
A
PPPoA, included in RFC1483, can be operated in either Logical Link Control-Subnetwork
Access Protocol or VC-Mux mode. As a CPE device, Vigor modem encapsulates the PPP session
based for transport across the ADSL loop and your ISP’s Digital Subscriber Line Access
Multiplexer (SDLAM).
To choose PPPoE or PPPoA as the accessing protocol of the internet, please select
PPPoE/PPPoA from the Internet Access menu. The following web page will be shown.
Available settings are explained as follows:
Item Description
PPPoE/PPPoA Client Click Enable for activating this function. If you click Disable,
this function will be closed and all the settings that you
adjusted in this page will be invalid.
DSL Modem Settings Set up the DSL parameters required by your ISP. These are
vital for building DSL connection to your ISP.
Multi-PVC channel - The selections displayed here are
determined by the page of Internet Access – Multi PVCs.
VPI - Type in the value provided by ISP.
VCI - Type in the value provided by ISP.
Encapsulating Type - Drop down the list to choose the type
provided by ISP.
Protocol - Drop down the list to choose the protocol, PPPoE
or PPPoA.
Modulation – Choose a suitable method for PPPoE/PPoA
connection.
