Vigor160 Series User’s Guide
70
Source IP Display the name of source IP object.
Local IP Address Display the private IP address of the local host offering the
service.
Backup Click it to backup current settings of Open Ports as a file.
Restore Click it to restore Open Ports configuration file.
To add or edit port settings, click one index number on the page. The index entry setup page
will pop up. In each index entry, you can specify 10 port ranges for diverse services.
Available settings are explained as follows:
Item Description
Enable Open Ports Check to enable this entry.
Comment Make a name for the defined network application/service.
WAN Interface Specify the WAN interface that will be used for this entry.
Source IP Use the drop down list to specify an IP object. Or click IP
Object link to create a new one for applying.
Private IP Enter the private IP address of the local host or click Choose
IP to select one.
Choose IP - Click this button and, subsequently, a window
having a list of private IP addresses of local hosts will
automatically pop up. Select the appropriate IP address of
the local host in the list.
Protocol Specify the transport layer protocol. It could be TCP, UDP,
or ----- (none) for selection.
Start Port Specify the starting port number of the service offered by
the local host.
End Port Specify the ending port number of the service offered by the
local host.
After finishing all the settings here, please click OK to save the configuration.
