Draytek Vigor2763 - Page 9

4
3
3
.
.
2
2
W
W
a
a
l
l
l
l
-
-
M
M
o
o
u
u
n
n
t
t
i
i
n
n
g
g
t
t
h
h
e
e
V
V
i
i
g
g
o
o
r
r
R
R
o
o
u
u
t
t
e
e
r
r
DrayTek Vigor2763 series routers have keyhole type mounting slots on the
underside to hang the router on, using screws attached to a wall or other
surface.
1. Drill two holes on the wall. The distance between the holes shall be 168mm.
2. Fit screws into the wall using the appropriate type of wall plug.
3. With the screws installed, the router can be slotted into place.
Note
The recommended drill diameter is 6.5mm (1/4”).
