Vigor2830 Series Quick Start Guide
3
Interface Description
Factory Reset Restore the default settings. Usage: Turn on the router (ACT LED is
blinking). Press the hole and keep for more than 5 seconds. When you
see the ACT LED begins to blink rapidly than usual, release the button.
Then the router will restart with the factory default configuration.
GigaLAN (1-4) Connecters for local network devices.
DSL Connecter for accessing the Internet through ADSL2/2+.
WAN2(Giga) Connecter for remote network devices.
USB Connecter for a USB device (for 3G USB Modem or printer).
PWR
Connecter for a power adapter.
ON/OFF
Power Switch.
