Dreame Vortech Z10 Station User Manual

8 9
ENEN
Fig. E-18-Fig. E-21
Fig. E-22-Fig. E-25
Fig. E-26-Fig. E-29
2. Use scissors to cut o the hairs and
bers that get stuck on the brushroller.
Wipe the dust from the notch and
transparent cover with a dry cloth or
paper towel. Thoroughly dry before
use.
2. Use scissors to cut o the hairs and
bers that get stuck on the brushroller.
Wipe the dust from the notch and
transparent cover with a dry cloth or
paper towel. Thoroughly dry before
use.
Cleaning the Multi-Surface
Brush
Cleaning the Soft Roller Brush
1. Turn the lock counterclockwise until it
stops, then remove the roller from the
roller brush.
1. As shown in the picture, press the
brush roller release button to remove
the roller from the slot.
4. Stand the brush roller upright for at
least 24 hours until it is fully dry.
4. Stand the brush roller upright for at
least 24 hours until it is fully dry.
3. When it is dirty, rinse the brush roller
with clean water until it is clean.
3. When it is dirty, rinse the brush roller
with clean water until it is clean.
2. After unlocking the motorized mini-brush,
remove the brush roller, then rinse and
clean it.
3. Stand the brush roller upright in a well-
ventilated area for at least 24 hours until
it is fully dry.
Cleaning the Motorized Mini-
Brush
1. Use a coin as illustrated to rotate the
lock counterclockwise until you hear a
click.
4. Once the brush roller is dry, reinstall it
by following the disassembly steps in
reverse.
FAQ
If the vacuum is not working properly, please refer to the table below.
Errors Possible Causes Solutions
Vacuum does not work.
The appliance is out of battery or
its battery level is low.
Fully charge the vacuum, then resume
use.
Overheat protection mode
triggered by a blockage.
Clean the suction opening or air duct.
Wait until the vacuum cools down,
then reactivate it.
The suction opening or air duct is
blocked.
Clear any blockage from the suction
opening or air duct.
Weak suction force.
The dust cup is full and/or lter
assembly is clogged.
Empty the dust cup and/or clean the
lter assembly.
An attachment is blocked. Clear any blockage in the attachment.
The motor makes a strange
noise.
Main suction opening or
extension rod is blocked.
Clear any blockage in the main suction
opening or extension rod.
The battery indicator is
solid red when charging
the vacuum.
Battery pack is damaged.
Please contact after-sales service for
maintenance.
The battery indicator blinks
red after turning on the
vacuum.
The motor temperature is too
high. / The bush roller is blocked.
/ The air duct is blocked.
Check these parts in turn.
The battery indicator
does not light up when
charging.
The vacuum is not properly
placed on the dust-removal hub.
Make sure that the charging contacts
of the vacuum is aligned with that of
the dust-removal hub.
The battery is charged and
switches to Sleep Mode
automatically.
The vacuum runs normally.
The problem persists after ruling
out the above two possibilities.
Please contact the after-sales
department for maintenance.
Charging too slow.
The battery temperature is too
low or too high.
Wait until the battery temperature
returns normal, and then recharge.
LED lights of the multi-
surface brush and
motorized mini-brush do
not work.
LED lights are damaged.
Please contact the after-sales
department for maintenance.
The dust collection status
indicator is solid orange.
The dust collection bag is
uninstalled or inappropriately
installed.
Before dust collecting starts, conrm
that the dust collection bag has been
installed or installed in place.
The dust collection status
indicator is blinking
orange.
The dust collection bag reaches
capacity or the air duct is
blocked.
Replace a new dust collection bag
or clean the air duct. Then press and
hold the dust collection button for 3s
to troubleshoot the problem.
Fig. E-17
Replacing the Battery Pack
The vacuum contains a removable
rechargeable lithium-ion battery pack
which has a limited number of recharge
cycles. After extended use, the battery
pack may no longer hold a charge. If this
happens, it means the battery pack has
reached the end of its life cycle and needs
to be replaced.
1. Press down the battery pack release
button and slide the battery pack to the
right, as illustrated, to remove it.
2. Install the new battery pack.
