Note: Running belt deviation is not covered by warranty, and is mainly maintained
and adjusted by users according to the instructions. Deviation will seriously damage
the running belt and affect its service life. Please adjust immediately if it occurs.
4. Deviation adjustment of running belt
» All treadmills have the running belt deviation adjusted before they leave the factory, but
after a period of use, the running belt deviation may occur, which may be caused by the
following situations:
» The main part is not placed stably. » The user's feet are not in the center of the
» Uneven force on the user's feet. running belt when exercising.
» The deviation caused by human factors will automatically return to normal after several
minutes of no-load operation. For some deviation phenomena that cannot be recovered
automatically, adjust the belt by adjusting the screw by half a turn, and the specific
operation is as follows:
TECHNICAL PARAMETERS
Types S310 S340
Operating Voltage 220V-50HZ
Maximum Load 120KG
Outline Dimension 1215*500*114mm 1215*540*930mm
Effective Running Area 390*1030(mm)
Peak Motor Power 3.0HP
Continuous Output Power 0.5HP
Speed 1-6km/h 1-10km/h
Functions Walking/ running
Protection Level Against Electric Shock Level I
Left deviation of running belt Right deviation of running belt
Left
Right
Tight
Loose
Left
Right
Tight
Loose
DREAVER - TREADMILL
9
