Dremel MS20 - Assembly and Setup Procedures; Attaching Blade onto Moto-Saw

Disconnect the plug from
the power source before
making any assembly, adjustments or
changing accessories. Such preventive
safety measures reduce the risk of starting
the tool accidentally.
Attaching Blade onto Moto-Saw
1. When facing front of tool, pull quick
change lever towards yourself to the
loosened position, Fig. 2.
2. Place bottom pin end of saw blade into
bottom corner of lower accessory holding
area. The blade teeth must be pointing
down, Fig. 3.
3. Place top pin end of saw blade into top
accessory holding area of tool by pivoting
it forward into top holding area of tool,
Fig. 4.
4. Push quick change lever away from you to
tightened position to secure blade,
Fig. 5.
To remove the accessory, reverse the above
steps.
9
Assembly
!
WARNING
7
FIG. 2
FIG. 3
FIG. 4
FIG. 5
