DRIFT HD Ghost Quick Start Guide

10
new features
SETTING PROFILES
All camera settings can be
saved by selecting Save
Settings from the Camera
Settings menu and choosing
a save profile: A, B or C.
Profiles can be loaded by
selecting Load Settings from
the menu, then A, B or C.
The camera will power
on in the same settings
configuration it was
powered o in.
VIDEO TAGGING
When activated, this feature
allows the camera to
continuously record video,
but only saving on ‘tagging’
important footage.
While recording video,
pressing the MENU button
will tag and save past,
present and future video.
For example, with a video
tagging interval of 30s
selected, on pressing MENU
while recording, the camera
will save the previous 30s,
the current 30s and an
additional 30s—a total of
1m30s of ‘tagged’ footage.
The Video Tagging feature
requires a micro SD card
with 4GB of free space to
function correctly.
SIMULTANEOUS PHOTO
While recording video,
pressing the MENU button
will simultaneously take a
still photo.
When using the two-way
remote control, press the
ACTION button for the
same result.
This feature is only available
when Video Tagging (left) is
turned o.

DRIFT HD Ghost Specifications

General

Video resolutions	1280 x 720, 1280 x 960, 1920 x 1080 pixels
Maximum frame rate	120 fps
Supported video modes	1080p, 720p, 960p
Video formats supported	H.264, MOV, MP4
Maximum video resolution	1920 x 1080 pixels
Photo mode	Yes
Sensor type	CMOS
Light exposure modes	Auto, Manual
Display diagonal	2 \
USB connector type	Mini-USB B
USB 2.0 ports quantity	1
Internal memory	0.256 GB
Compatible memory cards	microSD (TransFlash), microSDHC
Maximum memory card size	32 GB
GPS (satellite)	No
Product color	Black
Protection features	Water resistant
Battery voltage	3.7 V
Battery capacity	1700 mAh
Battery life (max)	- h

Weight and Dimensions

Depth	33 mm
Width	52 mm
Height	105 mm
Weight	167 g
