Page 18 For technical questions, please call 1-800-444-3353. Item 92623
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
Parts List
Part Description Qty
1 Hex Key 1
2 Backing Pad 1
3 Spindle 1
4 Half Circle Key (4x13) 1
5 Screw (5x16) 4
6 Spring Washer 4
7 Front Cover 1
8 Bearing (# 201) 1
9 Fender Ring (32) 1
10 1
11 Fender Ring (12) 1
12 Steel Sleeve (115B, 12x8x10) 1
13 Tap Screw (5x30) 4
14 Front Cover 1
15 Lock Pin 1
16 Lock Spring 1
17 Spindle Lock Cap 1
18 Hex Head Screw (8x16) 2
19 Handle 1
20 Bearing (# 101) 1
21 Triangle Press Cover 1
22 Spring Washer (4) 3
Part Description Qty
23 Screw (4x10) 3
24 Armature 1
25 Bearing (# 18) 1
26 Wind Shield Ring 1
27 Tap Screw (5x55) 2
28 Stator 1
29 Spring (# 110) 2
30 Brush Holder Cover 2
31 Carbon Brush (# 4100) 2
32 Brush Holder (# 4100) 2
33 Motor Housing 1
34A Upper Back Cover 1
35 Tap Screw (3x10) 2
36A Trigger 1
37A Speed Adjustment 1
38A Lower Back Cover 1
39 Screw (4x20) 4
40 Sheath (# 125) 1
41 Power Cord 1
42 Press Cable Board 1
43 Tap Screw (4x14) 2
