Drill Master 94245 - Parts List

Page 16For technical questions, please call 1-800-444-3353.SKU 94245
PARTS LIST
Part Description Q’ty
1 Guide Fence 1
2 Round-headRivet 2
3 Guide Fence Screw 1
4 Base Plate 1
5 Screw M6x16 1
6 Angle Bracket 1
7 Retaining Ring 1
8 Carriage Bolt M6x10 1
9 Washer 1
10 Wing Nut M6 1
11 Blade Cover 1
12 Blade Flange 1
13 Spring Pin 1
14 Sawblade 1
15 Inner Flange 1
16 Spindle 1
17 Shaft Key 1
18 Screw M4x8 4
19 Cover 1
20 Blade Guard 1
21 Screw M5x10 3
22 Bearing 6001Z 1
23 Front Cover 1
24 Bushing 1
25 Screw M5x14 3
26 Gear 1
27 Spring Washer 4
28 Spring Washer 1
29 Fender Ring 1
30 Oil Bearing 1
31 Housing 1
32 Spring 1
33 SpindleLock 1
Part Description Q’ty
34 Spring 1
35 BladeGuardLever 1
36 Fender Ring 1
37 Nut 1
38 DepthLever 1
39 Washer 1
40 Shelf 1
41 Carriage Bolt M6x14 1
42 Hex Bolt M6x16 1
43 Bearing 6000Z 1
44 Fender Ring 1
45 Armature 1
46 Bearing 607Z 1
47 Bearing Sleeve 1
48 Fan 1
49 Tap Screw ST4.8x60 2
50 Stator 1
51 Housing 1
52 Screw M5x58 3
53 Carbon Brush Holder 2
54 Carbon Brush 2
55 Carbon Brush Cover 2
56 Nut M5 2
57 Right Handle 1
58 Strain Relief 1
59 Tap Screw ST4.2x14 2
60 Power Cord Guard 1
61 Switch 1
62 Power Cord 1
64 Tap Screw ST4.2x12 1
65 LeftHandle 1
66 Tap Screw ST4.2x16 4
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts.
