Page 9For technical questions, please call 1-800-444-3353.SKU 94245
Make sure the extension cord is properly 7.
wired and in good electrical condition.
Always replace a damaged extension
cordorhaveitrepairedbyaqualied
electrician before using it.
Protect the extension cords from sharp 8.
objects, excessive heat, and damp or
wet areas.
RECOMMENDED MINIMUM WIRE GAUGE
FOR EXTENSION CORDS* (120/240 VOLT)
NAMEPLATE
AMPERES
(at full load)
EXTENSION CORD
LENGTH
25’ 50’ 75’ 100’ 150’
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
TABLE A
* Based on limiting the line volt-
age drop to ve volts at 150% of
the rated amperes.
Symbology
Double Insulated
Canadian Standards Association
UnderwritersLaboratories,Inc.
V~
Volts Alternating Current
A
Amperes
n
0
xxxx/min.
NoLoadRevolutionsperMinute
(RPM)
SPECIFICATIONS
Power Input 120 V~, 60 Hz, 10 A (peak)
Motor 5000 RPM, direct drive
LineCord 18 AWG x 2
Saw Blade 7-1/4”;24toothcarbidetipped
(included)
Cutting Capacity 2.5” at 90°; 1.7” at 45°
Arbor 5/8”; Spindle lock
Accessories Blade removal hex wrench
Features Automatic guard return
Weight 8.6 lb.
Toe Plate 10-5/8”Lx5-3/8”W
E194601
REV 10e
