Instructions for use TSE 120 / TSE 120 Plus
Drive Medical GmbH & Co. KG | As per: 24.03.2020 | Errors and alterations excepted
EN
Indication
INDICATION:
Use of the toilet hindered due to unadapted seat height
through limited ability to sit down and stand up along
with limited control of the trunk with functional disorder
of the lower extremity with signifi cantly restricted or
fully absent movement of the joints and/or limited mus-
cular strength of the lower extremity and/or damage to
the lumbar spine, hip and/or knee and/or damage to the
nervous system/central nervous system and/or damage
to muscle function with limited or absent stability of the
trunk.
Scope of delivery
1 x A Body
1 x B Support
2 x C Adjustable holder
2 x D Front support
2 x E Brace
2 x F Fixing screws (only for TSE 120)
2 x G Knurled nuts (only for TSE 120)
2 x H Star screw (only for TSE 120 Plus)
2 x I Top-mounting pin (only for TSE 120 Plus)
2 x J
Armrest (not for 520500300 TSE 120
without armrest)
1 x Instructions for use
1 x Vinyl gloves
TSE 120 TSE 120 Plus
1. Armrest
2. Armrest holder
3. Locking mechanism for adjustable holder
4. Body
5. Recessed grip (in the lid)
6. Lid
7. Fixing screw
8. Knurled nuts
9. Rear support
10. Adjustable holders
11. Front support
12. Braces
13. Hygiene openings
14. Star screw
15. Top-mounting pin
1
2
4
5
6
3
7
8
9
10
11
12
13
3
9
10
11
15
14
12
