Drive DeVilbiss TSE 120 - Cleaning | Maintenance; Height Settings; Technical Data

Instructions for use TSE 120 / TSE 120 Plus
13
Drive Medical GmbH & Co. KG | As per: 24.03.2020 | Errors and alterations excepted
EN
Height settings
The raised toilet seat can optionally be adjusted using
the adjustable holders (C) for an elevation of 8.5 cm,
12cm or 15.5 cm.
• Slightly push in the locking tabs (L) on the right and left
under the armrest holders and then lift the raised toi-
let seat.
• Pull out the adjustable holders (C) and adjust the
desired height (photo 10).
• Take care that the adjustable holders (C) on the right
and left are each connected at the same height.
• To adjust the height in the front, insert the supports (D)
in the corresponding opening until they audibly click
into place.
• Take care that the front supports (D) on the right and
left are each inserted at the same height.
• The front supports (D) can be set lower than the rear
support (B).
• Insert the body of the raised toilet seat (A) into the
adjustable holders (C) . In doing so, the adjustable hold-
ers (C) must engage with the locking tabs (L) in the body
(A).
• The adjustable holders (C) can only be inserted in one
direction into the raised toilet seat.
Product TSE 120 without armrest TSE 120 with armrest TSE 120 PLUS
Article number
520500300 520500400 520500500
Overall length 49 cm 49 cm 49 cm
Overall width 46 cm 55 cm 55 cm
Overall height 19 cm 38 cm 38 cm
Opening length 27 cm 27 cm 27 cm
Opening width 20.5 cm 20.5 cm 20.5 cm
Width between armrests - 46 cm 46 cm
Height adjustment 8.5 / 12 / 15.5 cm 8.5 / 12 / 15.5 cm 8.5 / 12 / 15.5 cm
Weight 2.6 kg 4.1 kg 4.1 kg
Max. load 120 kg 120 kg 120 kg
Color white white white
Material Plastic (PP / PA) Plastic (PP / PA) Plastic (PP / PA)
Technical data
Cleaning | Maintenance
• Clean regularly with a moist cloth!
• Do not use any aggressive cleaning agents!
• Do not use abrasive cleaners!
• Do not use any high-dose chlorine and vinegar-based
cleaners!
• To disinfect, a spray disinfectant can be used such as
Descosept AF or Bacillol AF.
• Check the screws regularly and tighten, if necessary.
• The product should not be exposed to temperatures
above 60°C for long periods of time (for example, use
in a sauna, etc.).
• In the event of defects, contact your specialist dealer
from whom you purchased this product.
