Blackcomb Installation and Operation Manual
31
CLEARANCES
(SINGLE WALL PIPE)
CANADA USA
A
14½" (368 mm) 14" (356 mm)
B
12" (305 mm) 12" (305 mm)
C
8¼" (210 mm) 7" (178 mm)
D
18" (457 mm) 17¾" (451 mm)
E
22" (559 mm) 22" (559 mm)
F
18" (457 mm) 17" (432 mm)
K
48" (1219 mm) 48" (1219 mm)
L
84" (213 cm) 84" (213 cm)
CLEARANCES
(DOUBLE WALL PIPE)
CANADA USA
A
6" (152 mm) 6" (152 mm)
B
11" (279 mm) 11" (279 mm)
C
5" (127 mm) 5" (127 mm)
D
9¾" (248 mm) 9¾" (248 mm)
E
21" (533 mm) 21" (533 mm)
F
15" (381 mm) 15" (381 mm)
K
48" (1219 mm) 48" (1219 mm)
L
84" (213 cm) 84" (213 cm)
Clearances for mobile homes
MOBILE HOME CLEARANCES (DOUBLE WALL
PIPE)
CANADA USA
A
6" (152 mm) 6" (152 mm)
B
11" (279 mm) 11" (279 mm)
C
5" (127 mm) 5" (127 mm)
D
9¾" (248 mm) 9¾" (248 mm)
E
21" (533 mm) 21" (533 mm)
F
15" (381 mm) 15" (381 mm)
K
48" (1219 mm) 48" (1219 mm)
L
84" (213 cm) 84" (213 cm)
