Page 35
Installation and Operation Manual - Escape 1200
ENGLISH
# Item Description Qty
34 AC02055 QUICK CONNECT THERMODISC 1
35 44028 CERAMIC THERMODISC F110-20F 1
36 AC02050 BLOWER ASSEMBLY WITH VARIABLE SPEED CONTROL (UP TO 100
CFM)
1
37 44085 RHEOSTAT KNOB 1
38 44087 RHEOSTAT NUT 1
39 44080 RHEOSTAT WITHOUT NUT (MODEL KBMS-13BV) 1
40 44073 CROSSFLOW BLOWER 115V-60Hz-39W 100 CFM 1
41 60013 POWER CORD 96" X 18-3 type SJT (50 pcs per carton) 1
42 AC01336 5"Ø FRESH AIR INTAKE KIT FOR WOOD STOVE ON PEDESTAL 1
43 49028 5" WHITE AIR INTAKE TERMINATION 1
44 30536 LEVELING BOLT 1/4 - 20 X 1'' 4
45 30185 17/64" AA TYPE WASHER BLACK 4
46 30100 BLACK HEX NUT 1/4 - 20 4
47 SE74266 ESCAPE 1200 PEDESTAL ASSEMBLY 1
48 PL74268 BACK OF THE BASE 1
49 SE74362 ESCAPE 1200 GLASS AND MOLDING KIT 1
