CHARGER INSTRUCTION MANUALC1 - XR AC/DC SMART BALANCE CHARGER
32
Introduction 3
Specication 5
MainFeatures 6
WarningandSafetyNotes 8
ProgramFlowChart 11
ProgramDescription 12
OperatingProgram 13
Explanation Of Buttons 14
Charging Program 15
Discharge Program 17
Lithium Battery Storage Program 18
Battery Memory Set And Call Out 19
Battery Checking 20
SystemSetup 22
FaultyOperation 24
CerticationInformation 25
AfterSaleService 26
Introduction
These operating instructions are designed to ensure that you quickly become
familiar with its functions. It is therefore important that your read right
through the Operating instructions, Warning and Safety Notes before you
attempt to use your new charger for the rst time.
EV-PEAK C1-XR integrates battery technology together with LCD screen. It is
equipped with 4 function buttons. Every operating procedures very intuitive.
When the battery is working, you can directly check the battery capacity,
battery voltage, charging time and internal resistance on the screen.
C1-XR comes with a memory module. Users can edit and save parameters of
dierent batteries. Once the battery parameters are edited, the shortcut for
parameters will be generated on the screen, which provides a simple on-click
interface for users.
C1-XR is built-in switching power supply. It can be powered up with 12V car
battery or 100-240V AC input, suitable for use with LiPo / LiFe / LiHV / Li-Ion /
NiMH / NiCd / Pb battery.
Please BE SURE to read these INSTRUCTIONS, WARNING and SAFETY NOTES
before you use the charger for the rst time.
It can be dangerous to mishandle batteries and battery chargers as there is
always a risk of batteries catching re and exploding.
Please read this entire operating manual completely and attentively before
using this product, as it covers a wide range of information on operating and
safety. Or please do use this product in company with a specialist.
