Compass calibration
Step 1: Horizontal Calibration
Calibrating the compass is a two step process: The first step: horizontal calibration, press the geomagnetic calibration
button then press the drone as shown below, and rotate it horizontally about 3 times. On the remote control once the
indicator light is on, the horizontal calibration is complete.
Step 2: Vertical Calibration
Rotate the nose of the aircraft up and down, as shown in the
figure below, turning the drone
about 3 times. On the remote control, once the light is on,
the vertical calibration is complete.
Note: The best distance during calibration is 1 m from the ground. Do not calibrate in areas with strong magnetic
fields, car parks and construction areas with underground fittings. Do not carry metal objects such as keys, mobile
phones, etc. with you when calibrating. Do not calibrate near large metal parts.
Search Area: Once the compass calibration is complete, the drone will be positioned horizontally. To release the take-
off, simply push the joystick to the lower left corner at 45°, while the right joystick is pushed to the lower right corner at
45°.
7
