Drop X User Manual

Electrical installation
The electrical installation may only be carried out by a licensed electrician.
PLEASE NOTE! Donotturnonpowertothepooluntilitislledwithwater!
The outdoor spa pool must be connected to a 3 x 16 A, 400 V (current) or a 1 x 16 A,
230 V (3 kW Lähde & Lampi) electrical connection. The electrical connection must
be protected with a ground fault circuit interrupter. The electric supply can be drilled
through any corner of the pool’s siding or a moving strap groove in the pool base. The
side behind which the control panel is located is marked on the pool.
PLEASE NOTE! Models: Drop X, Drop Vuolle, Drop S and Lähde must be connected
toa3x16A,400V(current)electricalconnection)Models:LampiandDropLähde
3 kW must be connected to a 1 x 16 A, 230 V connection. Drop Lampi with a extra
heatermustbeconnectedtoa3x16A,400Velectricalconnection.
PLEASE NOTE! The wires must be stripped to a length of approx. 20 mm, and the
earth connection must be completed appropriately.
 1. Checkthatthepoolislledwithwatertothelevelofthesurface 
suction drains.
2. Open the service hatch to access the control panel.
3. Connect the power cable to the control panel.
 4. Closetheservicehatch.
Electrical installation diagram
3 kW 1 x 16 A, 230 V
Electrical installation diagram
6kW3x16A,400V
