DROPSA VIP4 Tools - 10.2 VIP4 TOOLS Central Unit with Solenoid Valve; 10.3 VIP4 Tools Central Unit with Fixed Flow Rate Mini-Pumps and Proximity Sensor

10
10.2 VIP4TOOLS central unit with solenoid valve
VERSIONS
No. of dosing units
1-Litre reservoir
1
3135181
2
3135182
3
3135183
4
3135184
5
3135185
6
3135186
7
3135187
8
3135188
COMPONENTS
PART NUMBER
DESCRIPTION
3130139
Oil filling filter
1524445
Mixer Base
3103116C
Adjustable pneumatic mini-pump: along with the mini pump, assembly screws must also be
ordered. Code 14067 - quantity 2.
5717300
Tube, flexible Ø 4 (0.16 in.)
3044338
1-litre reservoir
1655583
Samba Level
ACCESSORIES
PART NUMBER
DESCRIPTION
5717301
Tube, flexible Ø 6 (0.24 in.)
3132572
1s ÷ 1 min. timer kit
45351
Solenoid valve 3v - 1/8” GAS – 24 Vdc
1524486
Lubrication nozzle 32 mm (1.26 in.)
1524487
Lubrication nozzle 48 mm (1.89 in.)
3226661
LRT 30 Oil for Steel – in 1l container
10.3 Vip4tools central unit with fixed flow rate mini-pumps and proximity sensor
VERSIONS
No. of dosing units
3-Litre reservoir
1
3135261
2
3135262
3
3135263
4
3135264
5
3135265
6
3135266
7
3135267
8
3135268
COMPONENTS
PART NUMBER
DESCRIPTION
3130139
Oil filling filter
1524515
Mixer Base
3103053
Fixed flow rate mini-pump with proximity sensor
5717300
Tube, flexible Ø 4 (0.16 in.)
6770072
3-litre reservoir
1655583
Samba Level
1523868
Inductive proximity sensor (PNP NO 10-30Vdc)
