DSC PC155O

16
PC1550 Version 4.1
[11] Zone Definitions
Page 10
NOTE: When defining zones, assign delay zones first to zones 1,2,3..., then assign the other zone types to the remaining zones
in any order desired.
Default
0 0 Zone 1
0 1 Zone 2
0 1 Zone 3
0 2 Zone 4
0 2 Zone 5
0 8 Zone 6
First Digit Second Digit
0 = Slow, Audible 0 = Standard Delay
1 = Slow, Silent 1 = Instant
2 = Fast, Audible 2 = Interior
3 = Fast, Silent 3 = Interior, Home-Away
4 = 24 Hour Bell
5 = 24 Hour Bell/Buzzer
6 = 24 Hour Buzzer
7 = Aux. Delay (Uses Auxiliary Entry/
Exit Times)
8 = Fire•
• •
• •
• Any one zone may be set as a FIRE zone.
[12] 1st System Option Code
Page 11
Default Zone Light ON Zone Light OFF
OFF Zone Light 1 Communicator disabled Communicator enabled
OFF Zone Light 2 TX limit to 24 hour period TX limit to armed period
ON Zone Light 3 Alarm display while armed No alarm display while armed
ON Zone Light 4 DTMF dialling Pulse dialling
OFF Zone Light 5 N.C. loops (except fire) EOL resistor loops
ON Zone Light 6 Keypad [P]anic audible (bell) Keypad [P]anic silent (bell)
[13] 2nd System Option Code
Page 11
Default Zone Light ON Zone Light OFF
ON Zone Light 1 Call 1st phone only Backup to 2nd phone
11
11
1
OFF Zone Light 2 Master Code not changeable Master Code changeable
OFF Zone Light 3 Bell Squawk enabled
22
22
2
Bell Squawk disabled
OFF Zone Light 4 PC16 OUT enabled PC16 OUT disabled
OFF Zone Light 5 6th code is maid’s code 6th code normal
OFF Zone Light 6 1400 Hz Radionics 2300 Hz Radionics
11
11
1
Do not program “OFF” unless 2nd phone number is programmed.
22
22
2
With Bell Squawk enabled, the bell/siren will sound one short burst on arming and two short bursts on disarming.
[14] 3rd System Option Code
Page 11
Default Zone Light ON Zone Light OFF
OFF Zone Light 1 User code required for bypass Code not required
OFF Zone Light 2 [
✱] [4] Enabled [✱] [4] Disabled
OFF Zone Light 3 Periodic downloading Periodic test transmit
OFF Zone Light 4 [
✱] [4] access code required [✱] [4] no code required
ON Zone Light 5 [P]anic audible (buzzer) [P]anic silent (buzzer)
OFF Zone Light 6 Partial closing identified Not identified
