DSC PC 1832 series Alarm Dialler wiring & programming RDC_3049_E_TA
Programming the DSC PC1832 series Alarm Panel for dialler operation:
Description
Location
Notes
Enable Dialler
380
Option 1
0ff = Disable
On = Enable (Default)
First System Option Code
380
Option 3 = DTMF
0ff = DTMF (Default)
On = Pulse
Message format
Phone 1
350
03 = DTMF Contact ID
Enter 0 3 0 3
System Account
310
Enter A for a 0
A = *1
E.g. 2090
2 *1 9 *1 #
Partition 1 Account
311
E.g. 2091
2 *1 9 1 #
Partition 2 Account
312
E.g. 2092
2 *1 9 2 #
Partition 3 Account
314
E.g. 2093
2 *1 9 3 #
Partition 4 Account
315
E.g. 2090
2 *1 9 4 #
Phone number
301
Enter # End of number
E.g. Phone Number Entry
1-2-3-4-5-6-7-8-#
Opening / Closing Reports
Routing
367 – 368 = Part 1-2
Option 1 = Phone 1
Off = Disable
On = Enable (Default)
Arming Report
339 = Users 1-16
340 = Users 16-32
Enter = 0101010101010101
Enter = 0101010101010101
Disarming Report
342 = Users 1-16
343 = Users 16-32
Enter = 0101010101010101
Enter = 0101010101010101
Telephone Line Monitor
345
Swinger Shutdown
377
Refer to manual

DSC PC1832 series Specifications

General

Zones	8 on-board, expandable to 32
Event Buffer	500 events
Communicator	Built-in digital communicator
Keypads Supported	8
Power Supply	16.5 VAC
Battery Backup	12VDC
PGMs	4
Communication	PSTN
Auxiliary Output	12VDC
User Codes	48 user codes
Wireless Compatibility	Yes, with wireless receiver
