5
PC2550RK KEYPAD
CHANGING SYSTEM FUNCTIONS
Changing Access Codes
The PC2525 features 8 programmable Access Codes. The first code is the Master Code, and the
remaining codes are normal Access Codes.
Programming Access Codes:
Enter [
∗
][5][Master Code]; the “Program” light will FLASH. The Zone Lights will indicate which Access
Codes have been programmed, and which Access Code is presently being programmed:
Zone Light is... Access Code is...
OFF not programmed
ON steady programmed
Flashing presently being programmed
When the [
∗
][5][Master Code] command is entered, Zone Light 1 will be ON to indicate that the Master
Code is already programmed.
Changing or Adding a Code:
To change the Master Code or Access Codes 2 through 8, enter the number of the code to be changed;
the corresponding Zone Light will begin to FLASH. For example, enter [1] to change the Master Code, or
enter [2] to change Access Code 2, and so on.
With the desired Zone Light flashing, enter a new 4-digit Access Code. Do not press [
∗
] or [#] when
entering the code. If an existing code is being changed, the new code will replace the old one. After the
code is entered, the keypad will beep 6 times and the Zone Light will stop flashing and remain ON.
If you want to program another code, press the number key for the code to be programmed, and enter
the new 4-digit code as described above. When all desired changes are complete, press the [#] Key to
return to “Ready”.
Erasing a Code:
To erase a code, enter [
∗
][5][Master Code]. Enter the number of the code to be erased; the Zone Light
for the code will FLASH.
Enter [
∗∗∗∗
] to erase the Access Code. When all desired changes are complete, press the [#] Key to
return to “Ready”.
IMPORTANT:
Do not erase the Master Code. If the Master Code is accidentally erased, contact your
installing company for assistance.
Door Chime On/Off
The Door Chime feature causes the keypad to beep whenever a zone defined as a “Chime” zone is
activated; your installer will inform you of which zones on your system will activate the Door Chime feature.
This feature is useful if the Entry-Exit door or doors are out of view, and you would like an indication of
when the door zones are opened and closed. Note that the Door Chime feature only functions when the
system is disarmed.
To turn the Door Chime feature on or off, enter [
∗
][4]. If the feature is being turned ON, the keypad
sounder will beep 3 times. If the feature is being turned OFF, the sounder will emit a single long tone.
8
Important:
Follow the instructions in the manual to test your system weekly. Follow the
guidelines for correcting system trouble conditions; have any system trouble
conditions you cannot correct yourself attended to by your installer.
The “Fire” light will come ON where there is any Fire
Alarm condition.
The “Ready” light will come ON when the system is
ready to be armed. When the “Ready” light is OFF,
there is an open zone on the system. The zone must
be closed or bypassed before the system can be
armed.
The “Armed” light will come ON to indicate that the
system is armed. The “Armed” light will FLASH to
indicate that the system is armed and that there is no
Entry Delay on any of the zones.
The “Memory” light will come ON where there are
alarms in memory. Enter [
∗
][3] to view the zones that
went into alarm while the system was armed. Press [#]
to return to “Ready”.
The “Bypass” light will come ON when there are
bypassed zones. Enter [
∗
][1] to view the zones that
are bypassed. Ensure that any bypassed zones are
bypassed intentionally before arming the system.
Press [#] to return to “Ready”.
The “Trouble” light will come ON where there is a
trouble condition present on the system. Enter [
∗
][2]
to view trouble conditions. Press [#] to return to
“Ready”.
The “Program” light will come ON when Access
Codes are being programmed and when system
functions are being changed.
Press [#]:
•when an error is made in entering an Access Code,
then enter the code again
•to return to “Ready” after using [
∗
] commands
Zone Lights 1 to 8
indicate zone activity.
With the system
disarmed, the Zone
Lights will come ON to
indicate when zones are
active, and the Zone
Lights will be shut OFF
to indicate that zones
are secure.
Ready
Armed
Memory
Bypass
Trouble
Program
Fire
F A P
2
3
4
5
6
7
8
1
F PA
18000120 R2
15
26
37
48
ZONE BYPASSING: Press[]then[1],then
press the zone you wish to bypass. Press
[#]toreturnto"Ready". ArmSystem.
PROGRAMMING USER CODES: Press [ ] then
[5], [Master Code] then press 1 thru 8 for
the user code you wish to program. Then
enter a four digit code, press [#] to return to
ready.
INSTANT ARM: Press [ ][9] before any user
code to arm system without entry delay.
ARM INTERIOR Press
QUICK EXIT Press
QUICK ARM Press
NOT
IN
USE
NOT
IN
USE
NOT
IN
USE
PC255ORK
TEST SYSTEM WEEKLY
[F] Key: Press and hold this key for 2 seconds to sound a Fire alarm
[A] Key: Press and hold this key for 2 seconds to generate an Auxiliary alarm
[P] Key: Press and hold this key for 2 seconds to generate a Panic alarm.
These keys will not function unless enabled by your Installer.
