DSG TH-D437H - Product Overview - Subwoofer; Rear View Connections

6
GB
Rear View of Subwoofer
1. 18V 2A Socket
2. COAXIAL Socket
3. OPTICAL Socket
1. POWER Indicator
Light up orange when the pairing
succeed.
2. PAIR Button
Pair with the main unit.
4. AUX Socket
5. HDMI OUT (ARC) Socket
3. AC 100~240V Power Socket
4. ON/OFF Switch
Switch the subwoofer ON or OFF.
Rear View
1
2
3
4
1 2 3 4 5
