Wall Mounting
• Installation must be carried out by qualied personnel only. Incorrect assembly can result in severe
personal injury and property damage (if you intend to install this product yourself, you must check
for installations such as electrical wiring and plumbing that may be buried inside the wall). It is the
installer’s responsibility to verify that the wall will safely support the total load of the Soundbar.
• Additional tools (not included) are required for the installation.
• Do not overtighten screws.
• Keep this instruction manual for future reference.
• Use an electronic stud nder to check the wall type before drilling and mounting.
1. Drill 2 parallel holes (Ø 4 mm each according to wall type) in the wall. The distance
between the holes should be 590 mm.
590 mm
Wall (Front view)
2. Firmly x 1 dowel (included) into each hole in the wall if necessary.
Dowel
Solid wall (i.e., Solid brick,
Solid concrete, Solid wood,
Solid wooden battens)
Drywall, Plaster wall,
Lath wall, etc.
3. Insert 1 screw (included) into each dowel. Be sure to leave a 40 mm gap between the
wall and the screw’s head. Lift the unit over the heads of the screws and slot into place.
40 mm
23 mm
