DStv 6S - Front and Top Panel

DStv HD Decoder Quick Start Guide
3
1. Reset button Press once to switch the decoder in and out of standby
Press and hold for a few seconds to reset (reboot) the
decoder
2. DStv HD This is the name of the decoder
3. P- button Goes to the previous channel
P+ button Goes to the next channel
4. Red, Amber, Green LEDS This LED is used to indicate various states that the
decoder may be in;
Flashing AMBER = unread mail message
GREEN blink = the decoder has received a command from
the remote
Solid RED = the decoder is on standby mode
Solid AMBER = the decoder is downloading software
Solid GREEN = the decoder is tuned to an audio or video
channel
Flashing RED = error
5. Model 6S This is the model number. Please remember to give us this
information when calling us with any technical queries
Front and Top Panel
2
1
4
3 5
