Back Panel
1 2 3 4 5 6 7 8 9
1 LNB in Connect the cable from the satellite dish to this input
2 RF IN Used for XtraView
3 RF Out Used to connect the decoder to a non-HD TV or for XtraView
4 USB Not active
5 HDMI Used to connect the decoder to a HD TV
6 RCA Used to connect the decoder to a non-HD TV
7 SPDIF Used to connect the decoder to your home theatre system
8 Ethernet Not active
9 Power input Connect the power supply to this input
