DT301
DT301:
 

Input/OutputPortsButtonFunctions

A HeadphoneJack  BUTTON  ACTION
B USB3.0Port  1 powerbutton
C DCPowerInput  2 programmablebutton
D GNSSmodule  3
BatteryLatch
• Pushtheswitchtounlockthelatch,
thanslidethelatchtolefttoremove
thebattery.

E BackCamera(optional)  4
RF switch


ENGLISH 2

