ENGLISH
2
3
ENGLISH
Packaging
The DT520 is packaged with recyclable materials and designed for maximum protecon in •
transportaon and handling.
When possible, please save the packaging carton and protecve inserts for re-use if there is ever •
a need to ship the DT520.
I/O Panels
Lower I/O Panel
The DT520 has a comprehensive set of I/O ports. The following ports are located along the lower
rear edge of the display unit.
Serial port1.
Audio-out jack2.
Microphone-in jack3.
Four (4) USB 2.0 ports4.
Enternet port5.
DC in jack6.
Fuse7.
DC power inlet8.
Power Switch9.
Front Panel Funcon Buons
The front panel of the DT520 features power and programmable buons.
Programmable buons: 10.
Power buon11.
Rear Mounng
The DT520 is designed to be secured to VESA-compliant mounng arms or stands. The VESA-
compliant mounng holes at the rear of the device will mate with VESA mounts or arms to meet
the requirements of the deployment.
The tablet without the VESA-compliant 1.
mounng arm
The display successfully mounted on a 3.
VESA - compliant mounting arm.
Aach the VESA-compliant 2.
mounng arm or stand to the
display using the same screws
removed in step 1.
The nine (9) buons
are intended to be user
programmable via soware in
applicable operang systems.
M
• ay be configured to perform different funcons, depending on the soware operang
system.
D
• epending on the OS, a brief, firm push will trigger soware-enabled entry into Shutdown
or Standby modes. Push in similar manner to Restart or to exit Standby mode.
P
• ush and hold for over 4 seconds to forcef
ully shut down the device. This method of
powering off should only be used when proper shutdown through soware is not possible.
Opons
The DT520 has a number of oponal configuraons in both soware and hardware.
These include:
Outdoor-viewable touch screen1.
SSD storage2.
Back-up baery pack implemented as an uninterrupble power supply (UPS)3.
U bracket4.
DC power cable5.
