1.General information
STARK is an industrial two-way radio transmitter with 1000 three-button CSS remote
controls.Designedto work in industrial automation, in hallsandwarehouses.
2.Technical data
• elementof system: CSS
• operatingfrequency: 868,30MHz/ 868,45MHz
• numberof individual remotes: 1000
• typeofcommunication: two-waycommunication
• battery: 3.6VR6
• batteryperformance: 3yearsat 100 cycles per day
• maximumrange: 1.2km
• EIRP: 10mW
• modulation: chirpspread spectrum
• dimensions: 115x72x38mm
• degreeof tightness: IP67
• workingtemperature: -20°Cto+55°C
8.8.8
seven-segment LCD display
3 function buttons
numeric keyboard
2 buttons to decrease and increase
the selected remote by one number
Fig. 1. View of the transmitter with a description of the buttons.
