DTS NETIMPRESS avant - Page 36

35
 Pin assignment
Signal Name Circuit lead
I/O
Serial mo
JTAG mod
Type color
1 O TCK TCK A white
14 - GND - white/black
2 I/O TTXD TDI A red
15 - GND - red/black
3 I/O TRXD TDO A green
16 - GND - green/black
4 I/O TBUSY TMS A yellow
17 - GND - yellow/black
5 I/O TAUX nTRST A brown
18 - GND - brown/black
6 I/O TAUX2 A blue
19 - GND - blue/black
7 I/O TAUX3 A orange
20 - GND - orange/black
8 I/O TAUX4 B grey
21 I/O TMODE B grey/black
9 O VCC C purple
22 - GND - purple/black
10 I/O /TICS B light blue
23 O /TRES D light blue/black
11 - GND - pink/black
24 O WDT D pink
12 - GND - black
25 I TVccd E yellow/green
13 I PROBE SELECT F light blue/white
Pin
No
