 Pin assignment
Pin
No.
1
I TVCCS A white
2
I/O CANL B red
3 - GND - black
4
- Reserved - blue
5
- Reserved - purple
6
I/O TIO C orange
7
I/O CANH B yellow
8
I/O TMODE C grey
9
I
PROBE
SELECT
D light blue
Signal
Name
Circuit
Type
lead
color
I/O
