DTS XR 8 Wash User Manual

DMX CHANNEL 15
Parameter: FOCUS
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-255 Linear Focus
DMX CHANNEL 16
Parameter: ZOOM
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-84 42 11°
85-170 127 15°
171-255 213 18°
DMX CHANNEL 17
Parameter: FROST (Priority on Zoom channel)
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
0-84 No lens
85-169 Frost 1
-
ARC 1200
XR 9 SPOT
24
DMX range
Value
Mid point
DMX value
Move
range
(degrees)
Mode Option Function
DMX CHANNEL 18
Parameter: RESET
170-255 Frost 2
0-9
No Effect
10-60 Lamp OFF (activ.after 3 seconds)
61-129
130-179
Internal motor reset
Total Reset
180-200
201-239
240-255
No Effect
Lamp ON (activ.after 3 seconds)
No Effect
