ARC 1200
XR 9 SPOT
4
1- TECHNICAL FEATURES
The XR9 Spot is fitted with a Philips MSR 575/2 discharge lamp
(GX9,5 lampholder base), with a colour temperature of 7,200 °K and a luminous flux of
49,000 Lumens.
Duration is 750 hours, with replacement recommended before 1000 hours
Other recommended lamps:Philips MSD 575 (GX9,5- 6000°K- 43.000 lm- 3000 hours)
The unit incorporates:
Motorized Focus system
Zoom (3 selectable beam aperture angles 11° / 15° / 18° with auto-focus)
Dimmer (emitted light is controlled by progressive and linear dimming).
Shutter (instantaneous shutter opening/closure)
Strobe: mechanical strobe effect (frequency variable from 0.85 flashes/sec to 10
flashes/sec).
2 gobo wheels: 1 rotating (7 indexable 16 bit gobos + open) and 1 fixed (11 gobos)
2 Colour wheels (16 colours )
Prism(indexable 3 facet prism rotating in both directions)
2 Frost Filter
Electronic or magnetic ballast
Pan: 540° in 3.9 seconds (8 or 16 bit) with auto repositioning system
Tilt: 320° in 2.6 seconds (8 or 16 bit) with auto repositioning system
USITT Standard DMX 512 input
26 DMX channels
4 -eight digit- LED display with 4 buttons
2 XLR connectors (In and Out) with 3 and 5 pins selectable by user
Power supply
Electronic ballast:
Universal power supply 90 - 260 V (50/60 Hz)
Power consumption: 750 W.
Remote Lamp on/off via DMX
Operating ambient temperature -10° / 40°
Weight
25 Kg (electronic ballast)
29 Kg (electromagnetic ballast)
Electromagnetic ballast:
230 V 50-60 Hz (Standard)
On request: 100 V 50-60 Hz /120 V 60 HZ / 208 V 60 Hz
Dimensions (LxWxH)
projector (450x470x670mm)
Packaging Dimensions
(LxWxH)
550 x 440 x 800 mm
Weight
41 Kg (electromagnetic
ballast)
37 Kg (electronic ballast)
