19- 4 MOTORS CONTROL CARD
34
XR 9 SPOT
Frost
(RED)
Fixed Gobo
(DARK ORANGE)
Iris
(LIGHT ORANGE)
Colour 2
(BROWN)
+
-
30 VDC
J1 from 8
Motors
Control card
