Dual CS 618 Q User Manual

13
Motor
Drive
Brushless Direct-drive, Quartz stabilised
Speed settings
33/45/78
Wow & Flutter
< ±0,07 % (DIN WTD)
Tonearm
Auto-Start/-Stop-Function
Auto-Stop with automatic tonearm lift
Bearing
4 x Pivot ball-bearing / twin Gimbal Mounting
Effective length
221,5 mm
Offset Angle
25,6°
Overhang
19 mm
Type
statically balanced
Stylus Pressure Range
0 to 4 g
Cartridge Weight Range
5 g to 9 g
Factory installed Pick-up
Ortofon 2M Blue
Replacement Stylus
Ortofon Stylus 2M Blue
Platter
Material
Aluminium Die-cast, Rubber Damping Inserted
Mat
Rubber 2,5 mm
Bearing
Hardened Steel Motor Spindle, Brass Bushing
Diameter
305 mm
Weight incl. Mat
1450 g
Plinth
Surface finish
Vinyl veneer: Black / Paint: Black Gloss / Wood Veneer: Walnut
Feet
Ø 62 mm / Elastomer Damping Element
Connection
RCA socket
Connection to Phono Input
YES
Connection to Line Input
YES
Digital Output
X
Dimension (closed dust cover)
435 x 367 x 145 mm
Dimension (open dust cover)
D: 415 mm / H: 400 mm
Weight
7 kg
Power Supply
The efficiency readings were taken with an input Voltage
of 230 V AC at 50 Hz
Type
HK-CW-102A200-CP
Input Voltage
100 (-10 %) V AC to 240 (+10 %) V AC
Frequency
50 / 60 Hz
Output Voltage
12 V DC
Output Current
2,0 A
Output Watt
24 W
Average Efficiency During Operation
≥ 86.2% @average of 25/50/75/100% loads 115&230VAC input
Power Consumption at Idle
< 0,1 W
