Wiring
3
Extension Cable(1M)
Accessories Included
HEAD UNIT(not included)
Once the remote has been mounted, connect the extension cable to the remote
and head unit as shown in the diagram above. When routing the extension cable.
be sure to avoid sharp objects, tight corners, and places where it might get
pinched as this could affect performance and cause damage to the unit.
Extension Cable(included 1M)
3.5mm jack connects directly into SWC
(Steering Wheel Control) input of any receiver
Nuts(x6)
Plain Washer(x2)
Spring Washer(x2)
Stainless mounting bracket(x1)
Rubber gasket(x1)
Bolts(x2)
