Packing List
● Mini dimension, MEMS gyroscope and accelerometer in one
chip, only 8 grams
● 32-bit high performance ARM MCU
● Original advanced attitude stabilization algorithm
● Support single/double aileron, fly wing and V-tail aircraft
● Support flaperon mixing
● Support aerobatic/3D airplanes
● Independent sensitivity adjustment of all 3 axes
● Support Futaba S. BUS protocol
● Support mode switch via extra channel, can be switched
between different modes
● Program via button and LEDs
● Support HV inputs
Caution: FC151 will take over all control channels
except throttle, if the setting of FC151 is
inappropriate, it might cause property damage or
personal injury. Please read the caution items and
the rest of this manual carefully before using FC151.
● It's recommended using this gyro on electric powered airplane
models or unpowered glider models
You need an at least 4-channel transmitter. If transmitter only has
4 channels, FC151 will work in auto-level mode by default and
can’t change modes during flight. We recommend you for 5
channel transmitter so that the 5th channel (usually the GEAR
channel) can be used for mode selection.
（
c
）
（
a
）
（
d
）
（
b
）
21021-1
Double
Side
Tape
（
a
）
FC151 Gyro x 1
（
b
）
Anti-shock double side tape x 1
（
c
）
3-signal wire (long) x 1
（
d
）
Single-signal wire (long) x 2
N RN RN R
FC151
6-axis Flight Control
MODE
Radio equipment
- 2 -- 1 -
Thank you for using Dualsky FC151 Flight Control
System. This gyro is equipped with latest MEMS
gyroscope & accelerometer chip, 32-bit MCU and
Dualsky original algorithm. It features at mini
dimensions, high sensitivity and friendly user
interface, more features are listed below:
● FC151 need 2~3 sec start-up time after powered on, please
keep the airplane still during the process
● Servos will only work after the FC151 start-up process ends,
this is normal.
● In auto-level mode, control surfaces of model which is still on
the ground may move to their maximum travel. This is Normal.
