N61e V1.0 or Higher
The N61e provides convenient and professional charging functions, which
are based on different batteries capacity and charging capabilities: FAST/
STD/ SLOW/ STORAGE. Instead of tedious manual setting, the operating
current is fixed at a variant charge rate (C). In the MANU function, you can
adjust the current from -3A to +10 A. The Discharge function is available in
the MANU, CYC or STORAGE functions. During operation, the current
can be adjusted except when using Constant Voltage. The detail below refers
to Table.N61e Operating Function Option.
Table. N61e Operating Function Option
FAST STD SLOW STORAGE CYC MANU
4/22
Li-Po
/ Li-Ion
/ Li-FePO4
2C 1C 0.5C 0.5C CHG or 1C
DCHG to 3.8V/S
(Li-FePO4:3.3V/S)
N/A
NiCd / NiMH 1C 0.5 C 0.2C As FAST Y
Lead-acid N/A 0.3C 0.1C N/A N/A
-3.0 ～
10.0A
Adjust-a
ble
Function
Charge
R
Battery
ating
For lithium batteries, at STG, the batteries will be charged or discharged to
3.8V (but 3.3V/S for Li-FePO4). At this point, the pack is approximately
half-full, which state of charge is ideal for long storage periods.
Still for lithium batteries, the FAST function is only recommended to new
chemistry packs which can be to charge up to 2C according to the
manufacturer.
Whatever you set, the actual operating current will be limited to Max power,
which is associated with input voltage and no more than 90Watts (@15VDC
Input). 72Watts@12VDC Input. Max discharge power is limited to 30Watts.
KEY FUNCTION
The ROTATING DIAL and the EXIT BUTTON are multi-purpose controls.
ROTATING DIAL
--Press instantly
z Enter into the selected profile on the profiles’ list.
z Start or stop editing parameters within a profile.
z Start or stop adjusting operating current as charging or discharging.
