N61e V1.0 or Higher
--Holding on, Press briefly (longer than 3 Sec)
z Charge Start, Charge Stop.
z Reset Battery Profiles.
z Clear the Error Message.
--Turn clockwise or anti-clockwise
z Scroll through the profiles’ list.
z Page up and down in submenu.
z Adjust parameter value in turn.
EXIT BUTTON:
--Press EXIT BUTTON instantly
z Return to upper menu.
z Disable to edit parameter.
QUICK REFERENCE GUIDE
z Connect N61e to a 12VDC power source. Observing proper polarity.
z Connect the battery to N61e. Observing proper polarity. Integrated
balancer is available for lithium battery only.
z Find out a suitable Battery Profiles. Or create and edit a new one.
z Press ROTATING DIAL (3 sec) to start charge or discharge.
WELCOME SCREEN
As soon as N61e powers on properly, the
welcome screen will appear on the LCD briefly.
It shows the manufacturer logo ‘DUALSKY’ and
the device name ‘N61e’, as well as the software
version ‘V ×.× B
DUALSKY N61e
V1.0 Build 025
uild ×××’.
At this time the cooling fan will run for a short time and both status LEDs
will flash on and go off. In this case you can check out whether they are
operating properly.
The system will then go to the most recently-used profile.
MENU STRUCTURE
The menu is constructed of two stages/layers, Top Menu and Sub-menu.
5/22
