powered off and repeat the appeal step.
* This operation does not change the throttle calibration value.
5. Timing and applicable motor
Summit ESC uses intelligent algorithms and automatic timing, so users no longer need to
experiment with different timing and motor compatibility. Summit is applicable to Dualsky ECO, EA, DA,
GA, MR, HD, etc series motors. It is also applicable to the same type of high quality senseless brushless
outer rotor motor on the market. At the same time, there is also good compatibility with the senseless
brushless inner rotor brushless motor.
6. Set idle speed and energy recovery
After the Summit throttle is calibrated, the default minimum throttle is the Freewheel. At this time, if
the throttle trim is pushed up a few and the motor is rotating, the gas engine idle speed effect can be
simulated. The idle speed has the following advantages:
* Motor acceleration response is fast * Stay in energy recovery mode * Better deceleration than
freewheel.
7. Set the brake
If the lowest point of the throttle is lowered from the unpowered position (by trim or throttle curve),
the throttle enters the brake zone. The braking force of the Summit series can be finely adjusted in the
range of 0-100%. The lower the throttle position, the greater the braking force, which is very suitable for
aerobatics such as F3A.
8. Set the throttle to lock switch
On the ground, if the throttle is accidentally touched, the propeller will rotate at high speed, which is
very dangerous. Summit ESC can't be avoided either. It is recommended to set the throttle lock by the
Throttle cut function, one more protection. At the same time, this function works well with the idle
function.
9. Switch and sleep
With the BEC's Summit ESC,
the BEC output can be controlled by
the FSS-4 switch. When the BEC is
turned off, the ESC also goes to sleep. The switch is of the Fail safe type, no switch or switch failure
occurs, and the ESC remains in operation.
The Summit HV series without BEC enters the sleep state when the throttle signal disappears for
more than 3S. After the signal is recovered, it must be lowered to the minimum throttle before the ESC
can be restarted. With this function, the model can be installed and connected to the main battery in
advance, and the remote control system is not turned on and placed in the waiting area.
* Sleepy ESC has a few milliamps of power for flight applications and is not recommended for more
than 24 hours.
10. Summit ESC has the following protection features:
