Dualtron STORM - Product Structure Overview; Electric Wiring Diagram; Scooter Dimensions

06
Dualtron Storm User Manual
Electric wiring diagram
Product size
1300mm
* Errors may occur depending on the measurement method.
1210mm
Handle width
600mm
Footrest width 318mm
Product structure
BLDC motor controller
Lithium-ion
battery pack
Charging
port*2
motor
BLDC
Meter
BUCK
DC-DC
vertical pole RGB LED
Very low power
consumption voltmeter
72V
motor
BLDC
front
Rear
1
2
L R
CON5 CON6 CON7
Inside the controller
Yellow turnYellow turn
left lamp right lamp
Red taillight
brake light*3
5 function
switch
+12
Steering
warning
LED controller
Horn
Night running Text light
RGB LED
Controller
Left front
swing arm
RGB LED
Right front
swing arm
RGB LED
vertical pole RGB LED
Connection stem
RGB LED
Right car body RGB LED
Left Rear
swing arm
RGB LED
Right Rear
swing arm
RGB LED
Left car body RGB LED
Text light
lights*2
Night running
lights*2
Left brake
power off
switch
Right brake
power off
switch
DT-STORM
K1
Light switch
K2
Steering
K4
Warning
K3
Horn
K5
Front drive
IN
OUT
DC25~95V
OUT
DC12V5A
IN
--
+
R
L
JS
SC
LR+
LR-
RR-
RR+
