Stopping Pressure Washer (See Fig 11)
Turn the on/stop switch to the OFF position.
Turn the fuel valve to the OFF position.
Turn off water and squeeze the trigger handle to release all water pressure.
OPERATION
Always relieve pressure from spray gun before pulling starter cord, including every failed attempt to start engine.
To avoid recoil, pull starter cord slowly until resistance is felt, then pull rapidly.
WARNING!
Pull cord recoils rapidly and pulls arm towards engine faster than you can let go which
WARNING!
Kickback forces result from pressing the trigger! Therefore, always hold the spray gun with
both hands! Pay attention to safe posture! Improper handling can lead to injuries!
could result in injury.
Using the Spray Gun (See Fig 12 - 13)
Flip the lock tab behind the trigger up or down until it clicks to apply or remove the safety. Pull back on the trigger to
begin operating pressure washer.
To stop water flow, release trigger.
FIG 12 FIG 13
TRIGGER
SLOT
LOCK OUT
15
Using Spray Nozzle (See fig 14-15)
To connect or disconnect spray tip, pull back on the quick-connect collar. Insert or remove spray tip then release collar.
When spray tip is connected, pull on the spray tip to make sure it is secured.
For general cleaning use the 40° spray tip. This option is for cement walkways.
FIG 11
ON
OFF
