85
E
Suspensions
Front
Hydraulic upside-down fork provided with outer adjuster
for rebound, compression, and preload (for inner springs
of fork legs).
Stanchion diameter:
43 mm
Travel along leg axis:
125 mm.
Rear
Of the progressive type, thanks to a rocker arm
connecting frame and upper pivot point of the shock
absorber. The shock absorber enables the adjustment of
rebound and compression damping and spring preload.
At the bottom pivot point it is connected to a light-alloy
swingarm. The swingarm hinges on a pivot pin passing
through the frame and engine.
The whole system gives the bike excellent stability.
Stroke:
71 mm.
Wheel travel:
128 mm
Exhaust system
Catalyzed in compliance with emission regulations.
Available colours (749/749S)
Available in:
Ducati yellow 473.201 (PPG);
Ducati anniversary red 473.101 (PPG);
metal-color frame and wheel rims.
