Water radiator fastening screw disassembly
Removing the frame special screw (For Multistrada 950
up to MY 18 and Multistrada 1200 from MY15 MY17)
Caution
engine. Also the front side of the motorcycle must be stable.
Lock the front wheel by means of suitable equipment. Position
of material between the crankcase and the jack itself. Loosen and
Smontaggio viti fissaggio radiatore acqua
Smontaggio vite speciale telaio (Per Multistrada
950 fino a MY 18 e Multistrada 1200 da MY15 MY 17)
ISTR 844 / 01
5
F1
D
E E1
D1
E2
D1
