GENERAL INSTALLATION DIAGRAM
L
1 3
4
8
7
6
5
2
2
9
9
9
9
SOFT-STOP
double speed with soft
approaching
Compatible with solar panel
power supply
AUTO-LOCK SYSTEM
Automatic lock the gate wen
closed.
Compatible with emergency
battery
REVERSAL SYSTEM on ob-
stacle detection
PEDESTRIAN access.
opens one wing partially
Low consumption technology
Icons meaning
