Ducati MONSTER 821 2016 User Manual

Engine rpm digital indication (RPM)
This function displays the number of RPM in digital
format (recommended for improved accuracy when
setting idle rpm).
Enter the Setting MENU. Select "RPM" option, by
pressing button (1) or (2).
Once function is highlighted, press CONFIRM MENU
button (4).
The Instrument panel displays the engine rpm as a
figure in the bottom left digits, in MENU 1.
The upper rev counter bar still indicates the engine
rpm.
The Instrument panel shows the numerical value of
the rpm with a precision of 50 rpm.
Press button (4) to quit.
Note
If the information is not available, the dashes " -
- - - - " and the rev counter scale start flashing.
MENU
EXIT
MENU
EXIT
MENU
EXIT
4
1
2
Fig 70
139

Ducati MONSTER 821 2016 Specifications

General

Displacement	821 cc
Bore x Stroke	88 mm x 67.5 mm
Compression Ratio	12.8:1
Transmission	6-speed
Final Drive	Chain
Frame	Tubular steel Trellis frame
Front Wheel Travel	130 mm (5.1 in)
Rear Suspension	Progressive linkage with adjustable monoshock
Rear Wheel Travel	140 mm (5.5 in)
Tires	Front: 120/70 ZR17, Rear: 180/55 ZR17
Wheelbase	1, 480 mm (58.3 in)
Engine Type	L-Twin, 4 valves per cylinder, Desmodromic, liquid cooled
Max Power	82.4 kW (112 hp) @ 9, 250 rpm
Max Torque	89.4 Nm (65.8 lb-ft) @ 7, 750 rpm
Fuel System	Electronic fuel injection, 53 mm throttle bodies with Ride-by-Wire
Exhaust	2-1 system with catalytic converter and two lambda probes
Front Suspension	43 mm upside-down forks
Front Brake	2 x 320 mm semi-floating discs, Brembo monobloc 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Wheels	10-spoke light alloy
Seat Height	785-810 mm
Curb Weight	206 kg
Fuel Tank Capacity	17.5 L
Safety Equipment	ABS, Ducati Traction Control (DTC)
Standard Equipment	Riding Modes, Power Modes
