Changing air filter (fig. 27.1)
Replace the air filter at the required intervals shown in
the routine maintenance chart. The air box is accessible
after lifting the fuel tank as described on page 39.
To remove the filter, release the cover clips (1) on both
sides of the air box and take off the cover (2).
Remove the filter cartridge (3, fig. 27.2) and fit a new
one.
Important
A clogged filter will reduce air intake, increase fuel
consumption, reduce engine power, and foul the spark
plugs. Do not use the motorcycle without filter or
suspended matters could get into the engine and cause
damage.
Install the filter into the seat in the air box as shown in
the figure and refit all the parts you have removed.
Important
If you are using the motorcycle on dusty or very
wet roads, replace filter more frequently than
recommended intervals.
fig. 27.1
fig. 27.2
