Wire color coding
P Pink
GR-Bk Grey-Black
Y-G Yellow-Green
G Green
R-G Red-Green
W-R White-Red
O-Bk Orange-Black
V-Bk Violet-Black
Y Yellow
W-B White-Blue
BN Brown
G-W Green-White
O-W Orange-White
R-Bk Red-Black
R-B Red-Blue
GR-R Grey-Red
R Red
G-Bk Green-Black
V Violet
Y-Bk Yellow-Black
GR Grey
G-B Green-Blue
Lb Light blue
Bk Black
Note
Wiring diagrams for both systems are at the end of this
