08
Model Reference picture In the package Handlebar assembly
Pro-III
Accessories:
- Allen wrenches
- Components for handlebar
assembly (hook, plastic
- Tyre inflation adapter
- Charger
- 2 RF Keys for scooter
ignition
Method:
1. Open the kickstand
2. Pick up the handlebar, place
the lever in the closed position
and lower the safety ring.
3. Install the handlebar on
4. Install the hook (see photo)
by approaching it to the rod,
making sure that it is aligned
the screws.
outside into the hole located
under the control panel.
6. Tighten the screws.
Method:
• Take the item out of the packaging
• Open the kickstand and check that the item is stable
• Open the handlebar stem and secure it by closing the lever of the closing mechanism
• Connect the display power cable to the main wiring (if necessary)
• Install the handlebar on the stem (do not crush the cables)
• Tighten the screws on the stem using the wrench supplied
• Adjust the stem closing mechanism*
