Ducati Scrambler 1100 User Manual

Tank filler plug
Opening
Insert the key into the lock.
Turn the key clockwise by 1/4 of a turn to release the
lock.
Lift the plug (1) at the back.
Closing
Lower the plug (1) at the front with the key inserted
and push it down into its seat.
Turn the key counter clockwise to the original position
and remove it.
Note
Plug can only be closed when key is inserted.
Warning
After refuelling, always make sure that the plug
is perfectly in place and closed.
1
Fig. 133
164

Ducati Scrambler 1100 Specifications

General

Engine Type	L-Twin, Desmodromic distribution, 2 valves per cylinder, air cooled
Displacement	1079 cc
Bore x Stroke	98 mm x 71.5 mm
Compression Ratio	11:1
Transmission	6-speed
Frame	Tubular steel Trellis frame
Rear Suspension	Kayaba monoshock, pre-load and rebound adjustable
Front Brake	2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
ABS	Bosch Cornering ABS
Seat Height	810 mm (31.9 in)
Power	86 hp (63 kW) @ 7, 500 rpm
Torque	65 lb-ft (88 Nm) @ 4, 750 rpm
Fuel System	Electronic fuel injection
Exhaust	Stainless steel muffler with aluminum covers
Front Suspension	45 mm upside-down fork
Rear Brake	245 mm disc, 1-piston floating caliper
Rear Wheel	10-spoke light alloy 5.50" x 17"
Front Tire	120/70 ZR18
Rear Tire	180/55 ZR17
Fuel Tank Capacity	15 L
Dry Weight	410 lb (186 kg)
